Rock Bucket
The Ulrich Attachments rock bucket is manufactured from a minimum of 1250N/mm² tensile, 1000N/mm² yield steel, with 450/560 Brinell Hardness steel wearing parts. The Ulrich rock bucket is built to suit all OEM Wheeled Loading Shovels for the harshest of environments. Ulrich offers multiple spec options for the rock bucket range including preferred teeth options, straight edge or Spade nose edge, Heavy-duty spill-guard options, and additional reinforced wear support.
Like all Ulrich products, the rock bucket is Made in Britain and is available with extended warranty.
Enquire now to receive a quote
Description
The rock bucket is designed for handling hard compacted materials and blasted rock within the mining and quarrying sector, as well as foundries and fabrications. The Ulrich rock bucket offers excellent break-out force and flawless geometry for best loading & unloading capabilities.
The Ulrich rock bucket range starts from a 2m³ capacity and Ulrich can produce up to a 6.5m³ capacity bucket within the offering. The Ulrich rock bucket can be produced to suit both fitting options including direct or quick coupler mounted.
| Capacity (m³) | Recommended Loader Size (tonnes) | TEETH | TEETH & SEGMENTS | SPADE NOSE | STRAIGHT EDGE |
|---|---|---|---|---|---|
| 2.0m³ | 10-12 | ||||
| 3.0m³ | 12-14 | ||||
| 4.0m³ | 14-18 | ||||
| 5.0m³ | 18-20 | ||||
| 6.0m³ | 20-24 | ||||
| 6.5m³ | 24+ |
